RGB+W Waterproof 19,2 W/M

STP32881

In 10 mm. size the RGB Stripled series offers all the advantages of chromatic dynamism both in the traditional configuration with LED 5050, long known as among the most reliable over time, and in the new configuration with the most recent LED 2110, latest generation emitters whose very small dimensions allow the perfect mixing of the individual red / green / blue emissions.

PRODUCTS CHARACTERISTICS

power:

19,2 W/m

ELECTRICAL CHARACTERISTICS

feeding:

24 V DC

insulation class:

Class III

MECHANICAL CHARACTERISTICS

Product IP rate:

IP65

HOLE RECESS DIMENSIONS

LED SOURCE DETAILS

led source type:

SMD LED - 2835

Color temperature:

RGB+W 3000K

DRIVER CHARACTERISTICS

LIGHTING DETAILS

PACKING DETAILS

WARRANTY

Drivers e Controlli
Sistemi di controllo RGB+W
Smartphone WI-FI Voice Control

Remote control + WI-FI ; 24V AC ; Class III

60 x 20,5 x 9 mm.

Drivers e Controlli
Sistemi di controllo RGB+W
Kit

Remote control + WI-FI ; 24V AC ; Class III

60 x 20,5 x 9 mm.

Drivers e Controlli
Sistemi di controllo RGB+W
Smartphone WI-FI Voice Control

WI-FI Tuya App ; 5 x 72W ; 24V AC ; 5A ; Barrier - free space 30m

114 x 38 x 20 mm.

Drivers e Controlli
Sistemi di controllo RGB+W
Smartphone WI-FI Voice Control

WI-FI Tuya App + push ; max 720W ; 24V DC ; Class II

179 x 56 x 30 mm

Drivers e Controlli
Sistemi di controllo RGB+W
Touch Panel

DMX512, RF 2.4GHz / RF remote control ; 85-265V AC ; Class II ; IP20

120 x 80 mm. h 37 mm.

Drivers e Controlli
Sistemi di controllo RGB+W
Touch Panel

DMX512 ; 4x 120 W ; 24V DC ; 4 x 24V DC ; 4CH, 5A/CH ; Class II ; IP20

170 x 50 mm. h 23 mm.

Drivers e Controlli
Sistemi di controllo RGB+W
Push Button

RF remote control / Push Dim. ; 4 x 180 W ; 24V DC ; 4CH, 5A/CH ; Class II ; IP20

175 x 45 mm. h 27 mm.

Drivers e Controlli
Sistemi di controllo RGB+W
Kit

Remote control ; 192 W ; 24V DC ; 4x 2A ; Class III

45 x 13 mm. h 5 mm.

Drivers e Controlli
Sistemi di controllo RGB+W
Smartphone / Bluetooth

Smartphone Bluetooth ; 24V DC ; 3x3A + 5A ; Class III ; IP63

86 x 21 mm. h 8,5 mm.

Drivers e Controlli
Sistemi di controllo RGB+W
Push Button

2x N.O. Push Buttons ; max 240 W ; 24V DC ; 12 / 24V DC ; 4 x 5 A (max 10A tot.) ; Class III ; IP20

88 x 54 mm. h 26 mm.

Drivers e Controlli
Sistemi di controllo RGB+W
Push Button

D-PWM ; max 240 W ; 24V DC ; 12 / 24V DC ; 4 x 5 A (max 10A tot.) ; Class III ; IP20

89 x 54 mm. h 26 mm.

Drivers e Controlli
Sistemi di controllo RGB+W
Multi Control

BUS DALI / Push N.O. / 0...10V - 1...10V ; max 480 W ; 24V DC ; max 4x 5 A ; Class III ; IP10

72 x 92 mm. h 62 mm.

Drivers e Controlli
Sistemi di controllo RGB+W
Multi Control

BUS DMX / Push N.O. / 0...10V - 1...10V ; max 480 W ; 24V DC ; max 4x 5 A ; Class III ; IP10

72 x 92 mm. h 62 mm.
